Stage surface size | 60×60mm |
Travel distance[±°] | 5~10 |
Load capacity[kgf] | 5 |
Travel mechanism | Worm gear |
Motorless: Applicable size | □28 Stepping motor specification |□38 Servo motor specification|□40 Servo motor specifications |
Guide | Cross Roller Guide |
Main material | Aluminum-Black alumite finishing |
Height of center rotation | 100±0.2mm|125±0.2mm|50±0.2mm|75±0.2mm |
Repeatability positioning accuracy [Within±°] | 0.003 |
